Cardan maintenance
RESTRICTED
Cardan.
D.
Cross
Trai!
Carriage
Fig. 35
pg•
E.
Cross
Trail
Knob M-3
F.
Dovetail
and Eccen-
tric
Fig. 43
Pg.
G. Level-
ing Knobs
N.O.P.
#650
pg. 23
H. Caging
Knob
(sight)
1. Drift
Pointer
Clearance
1. The cardan gudgeon bearings require yery little
oi!. They are oiled at
factory and
need no
oil unless removed
and cleaned.
If bearings are
cleaned, oil
with
i drop of
light oil.
Keep
bearings clean.
When
removing cardan
from case be careful
that the right cardan bearing is not damaged. This
bearing is
self-aligning locked bearing.
Clean with
alcohol or carbon tet. and wipe
with clean white cloth.
light film
the slides
and edges of
the cross trail carriage that
slide under the
shoes.
of movement.
After cleaning and oiling, check for freedom
1. Check for freedom of movement. It dirty, dis-
assemble, clean with alcohol or carbon tet. and
working parts with film of oil.
Keep free of dirt and dust.
Clean
with al-
cohol or carbon
tet.
Wipe with
white cloth
then oil with
film of light bombsight oil.
Check for freedom of movement
of eccentric disc..
CAUTION:
IF ECCENTRIC DISC IS DROPPED THE CAM-
WAY WHICH FITS OVER THE DOVE TAIL MAY BE DAMAGED.
ALMAYS CHECK FOR FREEDOM OF MOVEMENT OF THE EC-
CENTRIC DISC ON DOVE TAIL.
A. Check for precession of gyro in proper direct-
ion as knobs are used.
Bubble should move in the
same direction that the top of the knob
is turned.
(When gyro is running.)
B. Check for binding of shafts due to dirt, cor-
rosion,
etc. Disassemble, clean and oil if nec-
essary.
Check for rust, dirt and binding. Disassemble,
clean
and lubricate with petrolatum
(very light
film
) if necessary.
this
The drift pointer on the sight should clear
drift scale on
the Stab. by 012".
Obtain
clearance by stoning off the underside of
pointer.
the
2.
3.
a
2.
with
of
movement.
oil
all
clean
and
the
the
