Telescope cable installation
RESTRICTED
6. Leroing
the Roller
e.
Thread the
cable through
the front telescope
cradle gudgeon.
T.
Holding the
#5 sheave in place (taper pin hole
vertical,
large
end of hole up, remesh
the inte-
gral shaft pinion with the gear sector.
(Taper
pin hole in the
integral shaft should be in the
same position as
the sheave.)
INSERT THE TAPER PIN.
g.
Place the tel. quad. at zero sighting angle,
and place a fiber wedge between the quad. and rate
end housing
to hold
the quad. at exactly
zero;
in case of the modified M-6 make certain
the 20%
forward view is taken out.
h.
Thread the cable past #4, #3, #2 around #l and
through the eyelet in #l sheave,
holding a slight
tension on the tel. cable to hold it in the sheaves.
i.
Pulling on the
tel. cable slightly, remove the
wedge holding gear
her it.
sector.
Slip the cable sufficiently to align the gear
sector pointer with its index; extreme binding may
result due to the fact that the cable is all the
way
around the #l sheave; therefore,
i t
may be
necessary to pull on the cable with
the fingers
between
the #l and #2 sheaves to prevent damaging
the
cable.
a slight pressure on
the gear sector
pointer toward
max. sighting angle to shape cable
to sheaves, and
take up any slack.
Check adjust-
ment.
Correct
if necessary and thread excess cable
around eccentric.
Remove the wedge from the tel.
quad., and the
wedges from
i the cardan.
1. The roller, when properly zeroed, should rest
t te exact center of the disc witi
rate quad-
ant at zero tangent value and
trail arm
at zero mil. Fhere are three steps in zeroing of
the rolier.
A. ESTABLISH PROPER NUT GEAR CLEARANCE. The
purpose of this step is to assure that the trail
may be rotated to either of
its extremes with-
out
first having either the nut gear bottom
on the
upper portion of the rate rack housing
(when
zero
mils
is approached) or the retaining pin striking
the lower portion of the spindle lower bearing
housing when
maximum mils is approached.)
1.
PROCEDURE.
Remove rate end and es-
tablish
nut gear clearance
2 teeth---006---10
mils.)
in some
sights
the
spindle
gear or pin-
ion
does not bottom on the thrust washer when the
nut
gear
the
Bottoms
on the rate rack frame; therefore
nut gear must be rotated until the thrust
k.
Apply
the
with
the
arm
159
