Tachometer
RESTRICTED
motors and shafts,
Follow these instructions in
using a tachometer.
Place the tip of the drive shaft of the
indicator against the center of the shaft
or spindle of machine under test, so axis of each
coincides within reason.
Press the Push
Button full depth and re-
lease it quickly.
When pointer stops, read the result in
revolutions per minute.
Allow at least 5 seconds between trials.
Stop
Watches
• 969
Guage.
NOTE:
The last reading should remain on the dial
until the Indicator
has been placed in position
on the machine under test for a new
reading, press-
ing the Push Button as before.
A full push of the
Button resets the
counting mechanism,
winding the
time element, and a quick release
starts the es-
capement instantly.
The escapement button should
NEVER be depressed unless in the
act of obtaining
a reading.
LUBRICATION:
Oil the
shaft occasionally with a good
grade of watch oil through hole provided.
movement should not be tampered with except by ex-
perienced
instrument repair men.
Stop watches and interval timer clocks
special devices for measuring specific periods
of time. it
is necessary
in checking and adjust-
ing the bombsight equipment to make use of
measuring devices.
Handle them with extreme care,
do not
tinker with the mechanism.
movable seigne in used. tose is cent weet pithe
movable weight and
bracket.
(a)
aroor
(b)
(c)
(d)
The
and
movable
weight
the
A.E.S.
is
centered.
Place
guage
between
lead
screw
bear-
ing
198
